This series products have signifcative features for actual applications:
• The terminals have universal mounting feet and can be
installed on U type guide rail of TH35-7.5 and G type guide
rail of G32-15L,18. The enclosed type screw hole guarantees ideal operation of screwdriver.
• The terminal of multi sectional grades are equipped with
unitive accessories, such as terminal plated, grouping
separator and so on.
• Electric potential distribution can be realized through the
fxed bridgeware that is connected into center of terminal,
or realized through the side-insertion bridge-ware that is
connected into wiring chamber.
• Earth terminal and N line terminal that have the same confguration with common terminals.
Products Description
| Width/Thickness/Height | (mm) | 42.5/5.2/47 |
| Bolt Diameter | (mm) | M3 |
| Toggle Distance | （Nm) | 0.5-0.7 |
| Exhausted Line Length | (mm) | 8 |
| Voltage | (V) | 800V |
| Rated Working Frequency | (A) | 32A |
| Cross-sectional Area | (mm2) | 2.5mm2 |
| Rigid Conductor | (mm2) | 0.2-6 |
| Fexble Conductor | (mm2) | 0.2-4 |
Certifications:
CE, can be of ROHS at your decision
FAQ
Why should we choose Gaoke products?
A: Gaoke is a leading manufacture in the field of terminal blocks, connecting bars, din rail and copper accessories. We also provide customized solutions to meet various demands.
How can we ensure product quality from Gaoke?
A: Gaoke believes QUALITY is critical. We committed ISO9001 from paper to real work in each position in the company. From raw material supplier audits, incoming material inspection to quality control and final packing Every step is executed strictly to assure our product quality.
How long is the lead time?
A: Any order less than 500000 pieces can be completed in 30days.
